All prices plus inflation surcharge of 4.25%

1406	Excellent	Drill Rig for stairs building, pivoting

Art.- No.	For drill length [mm]	Drilling depth [mm]	Fixture	Foot measure outside [mm]	Foot measure inside [mm]	OAL [mm]		€
1406.320	max. 350	320	-	250 x 150	135 x 90	~490	Accessory	303.80
1406.322	max. 350	320	incl.	250 x 150	135 x 90	~490	Accessory	379.75

Fixture

Art.- No.	max. clamping width [mm]	Description		€
1402.000	0 - 90	Fixture	Accessory	75.90
1402.901	200	Set of Rails for broadening	Accessory	44.85

Universal drill chuck adapter

Art.- No.	SØ [mm]	Clamping range [mm]	Description		€
1402.043	13	1,5-13	Drill chuck adapter for drill stands		67.10

With additional handle, stageless adjustable depth stop and pivoting range up to 45°. Easy setting by 2 clamping levers. For power drills collar diameter 43 mm. Precise drilling in exact 90 -45° setting angle, especially suitable for the construction of stairs. Fixture set 1402.000: mountable on all FAMAG drill rigs with square foot. Due to the pivoting fi xture also applicable for curved cheeks. For staircase > 45° please use a shim. Tool holder and foot made of cast aluminium. Guide bars made of stainless steel.

Technical changes or mistakes reserved! All prices are recommended retail prices additionally value added tax.
